Product Summary
The ADAU1401YSTZ is a sigmaDSP audio processor with two ADCs and four DACs.
Parametrics
Absolute maximum ratings: (1)DVDD to GND: 0V to 2.2V; (2)AVDD to GND: 0V to 4.0V; (3)IOVDD to GND: 0V to 4.0V; (4)Digital Inputs DGND: -0.3V, IOVDD + 0.3V; (5)Maximum Junction Temperature: 135℃; (6)Storage Temperature Range: -65℃ to +150℃; (7)Soldering (10 sec): 300℃.
Features
Features: (1)28-/56-bit, 50 MIPS digital audio processor; (2)Complete standalone operation; (3)Fully programmable with SigmaStudio graphical tool; (4)28-bit × 28-bit multiplier with 56-bit accumulator for full double-precision processing; (5)Clock oscillator for generating master clock from crystal; (6)PLL for generating master clock from 64 × fS, 256 × fS,; (7)384 × fS, or 512 × fS clocks; (8)Flexible serial data input/output ports with I2S-compatible, left-justified, right-justified, and TDM modes; (9)Sampling rates of up to 192 kHz supported; (10)On-chip voltage regulator for compatibility with 3.3 V systems 48-lead, plastic LQFP.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADAU1401YSTZ |
|
IC AUDIO PROC 28/56BIT 48LQFP |
Data Sheet |
|
|
||||||||||||||||
|
ADAU1401YSTZ-RL |
|
IC AUDIO PROC 28/56BIT 48LQFP |
Data Sheet |
|
|
||||||||||||||||
